Panasonic Electronic Components AN48840B-NL

Name: AN48840B-NL
Brand: Panasonic Electronic Components
SKU: AN48840B-NL
Availability: InStock
Rating: 5.0 (507 reviews)

MFG Part Number: AN48840B-NL

Available Quantity: 29740 Pieces

Reference Price: USD 0

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: Panasonic Electronic Components

Brief Description: - MAGNET SWITCH BIPOLAR SMINI-5DA

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Magnetic Sensors - Switches (Solid State)

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: AN48840B-NL.pdf

Request Quotation for AN48840B-NL

Company Name

Contact Person

Phone Number

Address

Email

Message

AN48840B-NL Specifications

Manufacturer Part Number	AN48840B-NL
Future Part Number	FT-AN48840B-NL
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	-
AN48840B-NL Status (Lifecycle)	In Stock
Part Status	Obsolete
Function	Bipolar Switch
Technology	Hall Effect
Polarization	South Pole
Sensing Range	8mT Trip, -8mT Release
Test Condition	25°C
Voltage - Supply	2.5V ~ 3.5V
Current - Supply (Max)	85µA
Current - Output (Max)	15mA
Output Type	Push-Pull
Features	-
Operating Temperature	-25°C ~ 75°C (TA)
Package / Case	6-SMD (5 Leads), Flat Lead
Supplier Device Package	SMINI-5DA
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
AN48840B-NL Weight	Contact Us
Replacement Part Number	AN48840B-NL-FT
