Home / Products / Power Supplies - Board Mount / DC DC Converters / PTB48560BAS
Texas Instruments PTB48560BAS
- MFG Part Number
- PTB48560BAS
- Available Quantity
- 21000 Pieces
- Reference Price
- USD 48.119336
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- Texas Instruments
- Brief Description
- PTB48560 (30W) DC DC CONVERTER 1.8-3.6V 30W
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- DC DC Converters
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- PTB48560BAS.pdf
PTB48560BAS Specifications
| Manufacturer Part Number | PTB48560BAS |
|---|---|
| Future Part Number | FT-PTB48560BAS |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | PTB48560 (30W) |
| PTB48560BAS Status (Lifecycle) | In Stock |
| Part Status | Active |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 36V |
| Voltage - Input (Max) | 75V |
| Voltage - Output 1 | 1.8 ~ 3.6V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 8A |
| Power (Watts) | 30W |
| Voltage - Isolation | 1.5kV |
| Applications | ITE (Commercial) |
| Features | Remote On/Off, OCP, OTP, UVLO |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 82% |
| Mounting Type | Surface Mount |
| Package / Case | 11-SMD Module |
| Size / Dimension | 2.04" L x 1.04" W x 0.40" H (51.8mm x 26.5mm x 10.3mm) |
| Supplier Device Package | - |
| Control Features | - |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| PTB48560BAS Weight | Contact Us |
| Replacement Part Number | PTB48560BAS-FT |
